Black RS232 POS Customer Display VFD 96 Number And 13 Countrys Language

Product Categories

Shenzhen Alacrity Barcode Technology Co., Ltd

Contact Now

Black RS232 POS Customer Display VFD 96 Number And 13 Countrys Language

Name: Black RS232 POS Customer Display VFD 96 Number And 13 Countrys Language
Brand: symcode
Price: 1 USD

Wholesale Black RS232 POS Customer Display VFD 96 Number And 13 Countrys Language from china suppliers

Brand Name : symcode

Model Number : VFD-220E

Certification : CE / RoHS / FCC

Place of Origin : China

MOQ : 1pcs

Payment Terms : T/T, Western Union

Supply Ability : 50,000pcs per month

Delivery Time : Sample order:1-3 days / Bulk order:7-15days

Packaging Details : Carton box

Brightness : 500~1000 cd/m2

Power supply : 5-24V

Interface : Serial port (RS-232, powered by DC or powered by USB)

Display : VFD Bright blue-green fluorescent display

Display characters : 2 line x 20 characters / line, 40 characters, 5 x 7 Dots

MTBF : 25,000 hours

Support dimensions : Short support: 225mm (Contain base)

Pitching move angle : 45°, Can provide comfortable, and adjust the visual Angle

Storage Temp; : -40~80 A19

Operating Humidity : 10~85%

Storage Humidity : 10~90%

Stop bit : 1bit

Weight : 1.2Kg (gross)

Contact Now

Black Supermarket RS232 VFD POS Customer Display For POS System

1. High-luminance green dot matrix vacuum fluorescent display (VFD), can display English and digital cash registers such as status, the display is 20X2 to meet display requirements of overseas customers.

2. Display internal chip integration technology in the electronics industry, PCB Board adopts the best 1.6mmFR4 in the electronics industry, performance is stable and reliable.

3. Compatible "ESC/POS" standard generic instruction set does not need to install any driver, plugged in, select the right care model can work.

4. Display USB power supply DC 5V, can be provided by the host interface, or to take power from an external 5V adapter power supply, 5V power connector for round holes.

Model	VFD220E
Mode	VFD
Display words	20X2
Pixel pitch	5X7 dot matrix
Display colors	Blue,Green
Brightness	700 cd/m2
Display characters	96 number,13 countrys language
Typeface dimension	9.0mm x 5.25mm
Power	USB DC 5V
Consumption	3.0W
Lifetime	30000 H
Interface	USB
Baud rate	2400/9600BPS
Head dimension	224(W)X85(H)X60(D)mm
Pepe grid dimension	120mm
Display area dimension	187(W)X52(H)X93(D)mm
Max rotate angle	360°
Weight	1.5KG
Working Temp	-30°C—50°C
Humidity	30%—80%
Storage Temp	-40°C--60°C
Storage humidity	10%--90%

Black RS232 POS Customer Display VFD 96 Number And 13 Countrys Language
